Whether it be 2.4GHz remote control links, 5.8GHz high-definition video transmission, or GPS/Beidou navigation signals, modern drones have become veritable ‘radio frequency complexes’. In a crowded spectrum and complex electromagnetic environment, how can we ensure uninterrupted communication, snow-free video, and drift-free positioning? The answer lies in every inch of the PCB’s trace layout.

I.The unique operating environment of drone radio frequency systems

The design of RF PCBs for drones faces a unique dilemma: **high-power digital circuits coexist on a small board alongside highly sensitive analogue RF circuits. Strong sources of interference, such as motors and voltage regulators, are located in close proximity, and the compact structure of the drone makes it impossible to position the antenna far from the main board using long cables, as is possible with mobile phones.

Consequently, the objective of RF PCB design for drones is to create a ‘sanctuary’ for RF signals within the limited physical space available.

II. Layout Zoning Strategies for RF PCBs

1. Absolute isolation: The RF section (such as the 2.4 GHz PA and front-end FEM) must be physically isolated from other circuits. Ideally, the RF circuitry should occupy a corner of the board, and all layers beneath it (layers 2 and 3) must consist of a continuous ground plane to create a Faraday cage effect, blocking the penetration of digital noise from lower layers.

2. Localised Shielding: In high-end drones, pads are reserved during PCB layout for soldering a metal shielding enclosure. Enclosing the RF front-end, or even the entire flight control core, is the most effective means of suppressing radiated interference.

3. Interface Treatment: The feed point connecting the GPS antenna and the pin headers connecting the remote control receiver are both pathways for interference to enter. Filter circuits must be installed at these interfaces, such as series ferrite beads on signal lines or capacitors connected in parallel to ground, to filter out high-frequency noise.

III. Impedance Matching and Routing Details

Reflection is the greatest enemy of RF signals. All traces connected to antennas or RF power amplifiers must be strictly subject to 50-ohm impedance control.

• Calculation and Layup: This requires the dielectric thickness and permittivity to be determined during the layout design stage. For example, in a common four-layer board structure, the trace width required to achieve 50 ohms can be calculated by adjusting the distance between the top layer and the reference plane.
• Trace Requirements: RF traces must be short and straight; avoid 90-degree bends (use arcs or 45-degree angles instead), and traces must not cross different reference planes. Any via will introduce parasitic inductance and should be minimised. If a layer change is necessary, place a ground via adjacent to the via to provide a return path.
• Ground Enclosure: As many ground vias as possible should be placed on both sides of the RF signal line, and the top-layer ground copper should be used to enclose it, much like putting on a layer of ‘armour’, to prevent external noise from coupling in.

IV. New Trends in Addressing GNSS Jamming Environments

As application scenarios expand, drones are required to fly in underground tunnels, indoors, or in environments with strong electromagnetic interference. Drone designs based on UWB (Ultra-Wideband) positioning and visual navigation are gaining traction. UWB operates in the 3–10 GHz frequency band, placing higher demands on PCB material loss and impedance matching. When designing such boards, low-loss RF materials must be selected, and the microstrip lines between the UWB antenna and the RF chip must be exceptionally smooth to ensure the integrity of nanosecond-level pulse signals.

Conclusion

In the miniature electronic world of drones, radio frequency design is an art of precision. Only through meticulous layout, precise impedance control and thorough shielding measures can we ensure that drones remain ‘online’ in the skies at all times, executing every command with pinpoint accuracy.
