Rigid PCB Manufacturing

WHAT IS A RIGID PCB CIRCUIT BOARD?

The most common type of printed circuit board that is produced is the rigid PCB. Because of its robust substrate construction, the circuit board can be efficiently kept from distorting. The motherboard of a computer is arguably the most prevalent rigid PCB. The motherboard is a multi-layer PCB that facilitates communication between the CPU, GPU, and RAM as well as power distribution from the power supply.

When the PCB itself needs to be shaped and maintained for the duration of the equipment, rigid PCBs can be employed in any position. Simple single-layer PCBs to eight or ten-layer multi-layer PCBs are examples of rigid PCBs.

Flexible PCBs are not the same as rigid PCBs. One is pliable, while the other is inflexible. Their application circumstances differ as a result. Furthermore, Rigid-Flex PCBs are available. They are comparable to each other. Nonetheless, the single-layer, double-layer, or multi-layer architectures found in all rigid PCBs give them a similar range of applications. That is the situation.

Rigid printed circuit boards (PCBs) are a viable choice if you're searching for something affordable and scalable. A rigid PCB, with its higher circuit density, is an excellent option if you're searching for a hard-wearing circuit board because it also tends to be more robust than other boards, such as flexible PCBs.

As rigid boards can withstand high temperatures and levels of stress over their lifetime, they are very useful in goods and sectors where components must stay fixed.

Rigid PCB Manufacturing Service
PCB files, PCB technical requirements, BOM, Assembly or soldering technical requirements, to be offered by customer.
One Stop PCBA service: Production of PCB from 1-32 Layer, Assembly components/material purchase, SMT production, PCBA Testing, PCBA aging, PCBA Packaging, PCBA Delivery.

Rigid PCB Manufacturing Quality
1. CE-EMC, UL, FCC, SGS, ROHS, ISO9001:2008, ISO14001:2004, TS16949 Certified.
2. 8 Dustproof SMT Lines and DIP Lines.
3. ESD and dust proof working uniform implemented.
4. Operators are strictly trained, and approved for suitable working station.
5. PCBA Production Equipments：HITACHI Screen Printer,FUJI NXT-II & FUJI XPF-L Modules
Automatic Solder-Paste Printer,Reflow Oven，Wave Solder Machine，AI DIP Machine.
6. PCBA Testing Equipments：ORT Machine，Drop Test Machine，Temperature & Humidity Test Chamber, 3D CMM, ROHS Inspection Machine，AOI, X-RAY Inspection.
7. PCBA Testing Capability：AOI（Automatic Optic Inspection）,ICT（In-Circuit Test）,FCT（Functional Circuit Test）,X-Ray for BGAs.
8. Component Package including

Component range：
* 01005,0201,0402,0603,0805,1206,1608,2125,3216
* Fine Pitch QFP to 0.2mm
* BGA, Flip Chips, Connectors
* BGA to 0.2mm
9. SOP in every Work Station
10. PCB Materials: FR4, CEM-3, FPC, ALU

Rigid PCB Manufacturing Delivery Duration
Delivery for samples will be 10-15 WD after OEM Contact is signed and the Engineering Documents are confirmed.
For Mass production, based on the customer requirements, delivery can be done in several steps (Partial Delivery).

Rigid PCB Manufacturing Additional Information
1. After the confirmation of Prototype, MP will be started.
2. DIP Components will be positioned only once, minimum distance between components and PCB Board will be maintained.
3. Positioning Holes and Grounding holes will be protected by high temperature resistance tape.
4. EPE Antistatic packaging is used to prevent shock and other problems.

Rigid PCB Shipment
Standard Package
Each PCBA unit will be in Anti static bag, then the bubble bags, and then put into PCBA special carton
